Introduction

sanger-tol/curationpretext is a bioinformatics pipeline typically used in conjunction with TreeVal to generate pretext maps (and optionally telomeric, gap, coverage, and repeat density plots which can be ingested into pretext) for the manual curation of high quality genomes.

This is intended as a supplementary pipeline for the treeval project. This pipeline can be simply used to generate pretext maps, information on how to run this pipeline can be found in the usage documentation.

The above image shows the use of this pipeline inside of the manual curation process and follows the below major steps.

1. CRAM_MAP_ILLUMINA_HIC (ALIGN_CRAM) + PAIRS_CREATE_CONTACT_MAPS (CREATE_MAPS) - Generates pretext maps as well as a static image.

2. ACCESSORY_FILES - Generates the repeat density, gap, telomere, and coverage tracks.

3. PRETEXT_INGEST - Imports the generated tracks into pretext for visualisation.

Usage

[!NOTE] If you are new to Nextflow and nf-core, please refer to this page on how to set-up Nextflow. Make sure to test your setup with -profile test before running the workflow on actual data.

Currently, the pipeline uses the following flags:

• --input

  • The absolute path to the assembled genome in, e.g., /path/to/assembly.fa

• --sample

  • Sample is the naming prefix of the output files, e.g. iyTipFemo

• --reads

  • The directory of the fasta files generated from longread reads, e.g., /path/to/fasta/
  • This folder must contain files in a .fasta.gz format, or they will be skipped by the internal file search function.

• --read_type

  • The type of longread data you are utilising, e.g., ont, illumina, hifi.

• --aligner

  • The aligner you wish to use for the coverage generation, defaults to AUTO but options include bwamem2 and minimap2.

• --cram

  • The directory of the cram and cram.crai files, e.g., /path/to/cram/

• --map_order

  • hic map scaffold order, input either length or unsorted

• --teloseq

  • A telomeric sequence, e.g., TTAGGG

• --multi_mapping

  • Level of multi-mapping read filtering to perform whilst building the pretext map.

• --all_output

  • An option to output all maps + accessory files, the default will only output the pretextmaps where ingestion has occured.

• --skip_tracks

  • A csv list of accessory tracks to skip, options are: ALL, gap, coverage, telo, repeats, NONE. Default is NONE. Please note that capitalization matters.

• --split_telomere

  • A boolean to also generate the telomere track in 5Prime and 3Prime styles, this is also include the original telomere track.

• --pre_mapped_bam

  • A boolean option to use --cram as input for A pre-mapped bam file.

• --cram_chunk_size

  • The number of records in a cram file should be chunked into, defaults to 10000.

Now, you can run the pipeline using:

nextflow run sanger-tol/curationpretext \
  --input { input.fasta } \
  --cram { path/to/cram/ } \
  --reads { path/to/longread/fasta/ } \
  --read_type { default is "hifi" }
  --sample { default is "pretext_rerun" } \
  --teloseq { default is "TTAGGG" } \
  --map_order { default is "unsorted" } \
  --multi_mapping { default is "0" (for no filtering of multi-mapping reads)} \
  --all_output <true/false> \
  --outdir { OUTDIR } \
  -profile <docker/singularity/{institute}>

Warning: Please provide pipeline parameters via the CLI or Nextflow -params-file option. Custom config files including those provided by the -c Nextflow option can be used to provide any configuration except for parameters;

For more details, please refer to the usage documentation and the parameter documentation.

Pipeline output

To see the the results of a test run with a full size dataset refer to the results tab on the sanger-tol/curationpretext website pipeline page. For more details about the output files and reports, please refer to the output documentation.

Credits

sanger-tol/curationpretext was originally written by Damon-Lee B Pointon (@DLBPointon).

We thank the following people for their extensive assistance in the development of this pipeline:

• @muffato - For reviews.

• @yumisims - TreeVal and Software.

• @weaglesBio - TreeVal and Software.

• @josieparis - Help with better docs and testing.

• @mahesh-panchal - Large support with 1.2.0 in making the pipeline more robust with other HPC environments.

• @GRIT - For feedback and feature requests.

• @prototaxites - Support with 1.3.0 and showing me the power of GAWK.

Contributions and Support

If you would like to contribute to this pipeline, please see the contributing guidelines.

Citations

If you use sanger-tol/curationpretext for your analysis, please cite it using the following doi: 10.5281/zenodo.12773958

An extensive list of references for the tools used by the pipeline can be found in the CITATIONS.md file.
